The main alloy components of A335 P92 boiler tube are Cr:9%, Mo:1%, etc. Compared with SA-335P91 steel tube, SA-335 P92 seamless boiler tube appropriately reduces the content of Mo element, and adds a certain amount of W, which increases the molybdenum equivalent (Mo+0.5W) of the material from 1% of P91 steel to about 1.5%. High temperature strength and creep properties are improved. This enables it to be used in ultra-supercritical units and environments above 600 degrees Celsius.
A335 P92 high-pressure boiler tube is suitable for bending, curling and similar forming processes as well as fusion welding, and can be selected according to the design, working conditions, mechanical properties and high temperature characteristics.
Products Data
Chemical Composition(%) of ASTM A335 P92 Seamless Boiler Tubes
| Chemical Composition (wt%) | Minimum | Maximum |
|---|---|---|
| Carbon (C) | 0.07 | 0.13 |
| Silicon (Si) | - | 0.50 |
| Manganese (Mn) | 0.30 | 0.60 |
| Phosphorus (P) | 0.002 | 0.020 |
| Sulphur (S) | 0.001 | 0.010 |
| Chromium (Cr) | 8.50 | 9.50 |
| Molybdenum (Mo) | 0.30 | 0.60 |
| Nickel (Ni) | - | 0.40 |
| Vanadium (V) | 0.15 | 0.25 |
| Nitrogen (N) | 0.03 | 0.07 |
| Titanium (Ti) | - | 0.01 |
| Tungsten (W) | 1.50 | 2.00 |
| Zirconium (Zr) | - | 0.01 |
| Boron (B) | 0.001 | 0.006 |
| Aluminum (Al) | - | 0.02 |
| Niobium (Nb) | 0.04 | 0.09 |
Mechanical properties of ASTM A335 P92 Alloy Steel Seamless Boiler Tube
| Properties | Data |
| Tensile strength, min, (MPa) | 620 |
| Yield strength, min, (MPa) | 440 |
| Elongation, min, (%), L/T | 20/... |
1.Manufacture method: cold rolled, cold drawn, hot rolled.
2.Standard:ASTM A335
2.Grade:P92
3.Size range: 12.7mm*1.2mm - 325mm*50mm
4.Length:16000mm max,single or double random
Products display
ASTM A335 P92 heat resistant alloy pipe
Why Choose GNEE
The A335 P92 boiler tube produced by GNEE follows the execution standards of ASTMA335/A335MASTMA213/213M and is manufactured by hot rolling and forging, which is convenient for various operations during manufacturing and installation.
A335 P92 boiler tube also has a variety of options in specifications and sizes, which can be customized according to the specific needs of customers. For example, its outer diameter can range from 57mm to 762mm, and the wall thickness ranges from 5.0mm to 130mm.
GNEE also provides ASTM A335 P92 high-temperature tubes in the form of round tubes, square tubes, rectangles and hydraulic tubes.
If you are looking for steel pipe, please contact us in time to get a quote! sales@gneetube.com
GNEE CUSTOMER VISIT
GNEE FACTORY ENVIRONMENT
GNEE PACKAGING AND SHIPPING
FAQ
Q: Do you have quality control system?
A: Yes, we have our own quality control laboratory.Third party testing servicesare also available.
Q: What services do you provide?
A: Customized service for each customer, please feel free to contact us!
Q.What is your lead time?
A. Regular stock is usually 10 days. Depends on the products.
