DIN 17175 St45.8 High-Pressure Boiler Tubes

St45.8 is the boiler quality carbon steel tube grade of the German standard DIN 17175, carried under material number 1.0405. It is a seamless tube steel intended for heating surface tubes in high pressure boilers, and it is applied where the working pressure is above 9.8 MPa and the metal temperature runs between 450°C and 650°C. Economisers, superheaters, reheaters and petrochemical process lines are the classic duties for this grade.

Grade Overview and Position in the DIN System

Standard: DIN 17175, seamless tubes of heat resistant steels

Grade: St45.8, material number 1.0405

Steel type: non-alloy boiler quality carbon steel, delivered seamless

Main application: heating surface tubes of high pressure boilers and process pipework

Typical counterparts: European pressure tube grades of similar tensile level and Chinese 20G boiler tube steel under GB/T 5310

The extra cost of an alloyed grade such as 13CrMo44 is only justified once the duty demands it, so St45.8 remains the workhorse where the steam side still sits inside the strength envelope of a plain carbon tube. Wall thickness, outside diameter and length are agreed against the boiler design, and each length is certified against the ordered grade.

Heat Treatment of St45.8 Seamless Steel Tubes

Treatment Temperature Remark
Hot working range 1100 to 850°C Forging, rolling and piercing window
Normalising 870 to 900°C Standard delivery treatment for the grade
Quenching and tempering Not applicable The grade is not supplied as a quenched and tempered product

Because St45.8 is a non-alloy grade, its properties come from normalising rather than from an alloy addition, so the treatment temperature range is respected closely in the mill to keep the grain size uniform along the body of the tube.

Chemical Composition

Element C Si Mn P S
St45.8, percent by mass 0.21 max 0.10-0.35 0.40-1.20 0.030 max 0.030 max

Chromium and molybdenum are not specified additions in this grade; they remain at residual level. The manganese range of 0.40 to 1.20% is what lifts the grade above ordinary structural tube steel, since manganese raises the tensile level while the low phosphorus and sulphur limits protect ductility and impact behaviour in the finished tube.

Mechanical Properties

Property Requirement
Tensile strength 410-530 MPa
Minimum yield strength 255 MPa
Elongation 21% min

Room temperature testing is the acceptance basis. In design work the elevated temperature yield strength and creep data of the grade are used instead, because a carbon steel tube loses strength steadily as the metal temperature climbs towards the upper end of its service range.

Supply Condition and Applications

DIN 17175 St45.8 seamless steel tubes are delivered in a suitable heat treated condition. Normalising, annealing, tempering from the quenching temperature and treatment by the isothermal transformation method are all recognised delivery routes, selected so that the specified tensile and elongation values are met without further heat treatment in the fabricator's workshop.

Heating surface tubes of high pressure boilers: superheaters, reheaters and economisers

Steam and hot water pipework in power stations

Petrochemical process lines and heat exchanger tubes

Pressure parts, flanged connections and header stubs in boiler assemblies

The grade bends, expands and welds readily, which is why boiler makers use it for tube bank fabrication where many joints and bends are produced from one tube length. Welding follows normal carbon steel practice with a low hydrogen approach on heavy walls, and the finished joint is inspected together with the tube body.

Frequently Asked Questions

Q: What does St45.8 mean in the DIN 17175 system?
St stands for steel, 45 indicates the tensile level of the grade and the figure 8 identifies a boiler tube quality steel with a guaranteed minimum yield strength for elevated temperature service.

Q: What is the material number of St45.8?
The grade carries the material number 1.0405 in the German materials register.

Q: What pressure and temperature range does it serve?
High pressure boiler systems operating above 9.8 MPa with metal temperatures from about 450°C to 650°C, depending on wall thickness and design code.

Q: Does the tube need heat treatment after delivery?
No. It is normalised or otherwise heat treated at the mill to meet the specified properties, and it normally enters fabrication without further treatment.

Q: Is St45.8 an alloy steel?
No. It is a non-alloy boiler quality carbon steel and depends on carbon and manganese rather than on chromium or molybdenum for its strength.

Q: How is quality verified before dispatch?
Chemical analysis, tensile and elongation testing, dimensional checks, surface inspection and non-destructive examination are performed on the finished tube and reported on the mill certificate.
